MAN CLA 26.280 6x4 Tipper

Model : CLA 26.280 6x4 TIPPER Engine : MAN D-0836 - Six-cylinder in-line Diesel Engine with Direct Injection, Turbocharged and Intercooled - Displacement 6.9 Liters - Power output 280 hp ( 206 kW) @ 2400 rpm - Torque 1100 Nm @ 1300-1700 rpm - Economic speed range 1400-1700 rpm - Emission EURO-III Clutch : - Single dry plate pull type power assisted asbestos free clutch - Clutch Plate Diameter 430 mm Gearbox : ZF 9S-1110 TO - 9-speed synchronised range gearbox with crawler and reverse gears. Over Drive - Force-feed oil lubrication by oil pump. Full flow oil filter Exhaust : Horizontal Exhaust toward rear PTO : PTO Tipper Pump Front Axle : MAN Heavy Duty straight FM 08 Type Rear Axle : MAN FORCE H9 & HD9 13120 Planetary - Hub reduction with inter Axles differential lock - Bogie suspension on Tandem Axles with stabiliser bar and radius rods to ensure stability in off road conditions - Rear Axle Ratio 7.63 : 1 - Tyre : 11.00 R20 Chassis DIMENSIONS in millimeters ( mm) Wheelbase ( A) 3825 Front Overhang ( B) 1293 Rear Overhang ( C) 900 Overall Length ( D) 7507 Front Track ( E) 2075 Rear Track ( F) 1815 Minimum Ground Clearance ( at front) ( G) 385 Turning Circle Diameter ( meters) ( H) 19.5 Distance between Two Rear Axles ( J) 1400 Cabin Length( K) 1790 Over Chassis Height from Ground ( Unladen) ( L) 1157 Chassis Height from Ground ( Laden) ( M) 1107 Overall Height from Ground ( Unladen) ( N) 2878 Overall Height from Ground ( Laden) ( O) 2838 Frame Length behind Cab ( P) 5399 ( Kerb Weight) Unladen( kg) Laden ( kg) Front Axle 3550 7500 Rear Axle 4300 23000 Total 7850 26000
